Dismantling / installing the hygiene strip
50 11/2020 243343V03_EN
4.16 Dismantling / installing the hygiene strip
Dismantling the hygiene strip:
b Push the hygiene strip 1 upwards motion into the pin.
b Remove the strip forwards.
Installing the hygiene strip:
b Place the hygiene strip 1 onto the pins.
b Push the strip down until it sits tightly in the pins.
4.17 Dismantling / installing the scraper
Dismantling:
b Loosen star handles on the left and right.
Installing:
Assembly occurs in reverse order to dismantling.
Attention!
Only carry out this work after the cut-off knife has been
removed.
