Operation

Machine overview

10 11/2020 243343V03_EN

2.1 Machine overview

2.1.1 General overview

1 Main switch

2. Control panel

3 Feed chamber

4 Knife box door

5 Discharge conveyor

Rear view

6 Discharge conveyor connection

1 2 3 4 5

TR_0116_1

AM_0016
