Troubleshooting at a glance
11/2020 243343V03_EN 81
9.2 Troubleshooting at a glance
Malfunction Cause Remedy
Machine does not start Mains plug not plugged in Plug in mains plug
Main switch is switched off Switch on the main switch
Knife box cover not closed Close knife box cover
Discharge conveyor cover not
attached
Attach discharge conveyor cover
Separating slide not completely
inserted
Insert separating slide up to the
stop
Connector of the discharge con-
veyor not plugged in
Plug in the connector of the dis-
charge conveyor
Motor thermal protector overheats
during operation
Let the motor cool down
Pre-compression does not function Pre-compression is set to "0“ Increase setting for pre-compres-
sion pressure
Cut-off blade is scraping on the
gate
Cutting gap between gate and cut-
off cutter is not correct
Adjust cutting gap
Cut-off lengths do not match the
setting
Incorrect setting of the mode switch Set mode switch according to the
installed knife
Cut-off lengths are irregular Product too soft or too fresh Chill the product slightly
Cut-off knife pulls threads Cutting gap between gate and cut-
off cutter is too large
Adjust cutting gap
Cut-off knife is dull Sharpen the cut-off cutter
Tip of the cut-off cutter too short
due to re-sharpening
Replace cut-off knife
Bacon is de-rinded too sharply De-rind bacon less sharply
Cross section not OK Cut-off knife is dull Sharpen the cut-off cutter
Grid blade is blunt Sharpen grid blade
Tip of the cut-off cutter too short
due to re-sharpening
Replace cut-off knife
Product stabilisers not removed
when cutting with spacer frame
Remove product stabilisers
Product stabilisers not inserted for
soft cutting material
Insert product stabilisers
Product stabilisers inserted incor-
rectly
Check arrangement of the product
stabilisers
Product temperature not correct possibly chill slightly
Bones in the gate (especially with
cooked foods)
Remove grid and remove bones
Pre-compression set incorrectly Adjust pre-compression
