Trio Motion Coordinator MC206 User Manual

12-26Using the Trio ActiveX Control
Input / Output Commands
Trio Motion Technology
Record
Description:
Performs the corresponding RECORD(…) command on the Motion Coordinator
Syntax:
Record(Transitions, TablePosition)
Parameters:
Return Value:
TrioPC STATUS .
Regist
Description
Performs the corresponding REGIST(…) command on the Motion Coordinator
Syntax:
Regist(Mode, Dist)
Parameters:
Return Value:
TrioPC STATUS .
short
Transitions:
Number of transitions to record.
long
TablePosition:
Start position in the table to store the transitions.
short Mode:
Registration mode
1. Axis absolute position when Z Mark Rising
2. Axis absolute position when Z Mark Falling
3. Axis absolute position when Registration Input Rising
4. Axis absolute position when Registration Input Falling
5. Sets pattern recognition mode
double Dist:
Only used in pattern recognition mode and specifies the dis-
tance over which to record the transitions.
