4-4 Daughter Boards
Fitting and Handling Daughter Boards
Trio Motion Technology
There are 15 types of daughter boards currently available:
Note:
For volume / OEM applications, Trio can produce custom daughter boards for
specific customer applications where required.
Daughter boards marked * are for use with MC206 and MC224 only.
Fitting and Handling Daughter Boards
The axis daughter boards are normally supplied fitted into a Motion Coordina-
tor system. If daughter boards need to be moved or replaced the following
sequence must be followed.
The axis daughter boards are supplied in an anti-static bag or box. This should
be used to hold the axis daughter board at all times when not installed in the
Motion Coordinator.
Product
Code:
Description
ATYPE/
COMMS
TYPE
P200 Servo Encoder 2
P210 Servo Resolver 5
P220 Reference Encoder 3
P230 Stepper 1
P240 Stepper Encoder 4
P242 Hardware Pswitch 10
P260 Analog Output 6
P270 SSI Absolute Servo 7
P280 Differential Stepper 4
P290 CAN 8
P291 SERCOS * 24
P292 SLM (Drivelink) 22
P295 USB Interface 21
P296 Ethernet * 25
P297 Profibus 23
