2-20 Hardware Overview
Motion Coordinator Euro205(X)
Trio Motion Technology
Euro205X - Feature Summary
Size
170 mm x 129 mm Overall (160mm x 100 mm PCB)
25mm deep
Weight
170 g
Operating Temp. 0 - 45 degrees C
Control Inputs
Forward Limit, Reverse Limit, Datum Input, Feedhold
Input.
Communication Ports
2 RS232 Channels: 9600,19200,38400 baud, 1 RS485
Channel + 1 Fibre Optic Channel (using adapter)
1 CAN channel built on to motherboard
Position Resolution
32 bit position count
Interpolation modes
linear 1-5 axes, circular, helical, CAM Profiles, speed
control, electronic gearboxes.
Programming
Multi-tasking Trio BASIC system, maximum 7 user
tasks.
Speed Resolution
32 bits. Speed may be changed at any time. Moves
may be merged.
Servo Cycle
250us, 500us or 1ms (default)
Memory
256 Kbytes battery backed + flash program memory.
Power Input
500mA at 5 V d.c. (+/-12v at 25mA required for DAC
output)
Amplifier Enable Output
NO solid-state relay. Maximim load 100mA, maximum
voltage 29V.
Analog Inputs
2 x 12 bit 0 to 10V
Digital Inputs
16 Opto-isolated 24v inputs
Registration Inputs 4. One per axis shared with inputs 0 to 3.
Encoder Inputs 4 differential 5V inputs, 6MHz maximum edge rate
Stepper Outputs
4 differential (5V) or open collector (5 to 24V) step &
direction outputs. Maximum frequency 500kHz (OC),
2MHz (Differential).
Digital Outputs
8 Opto-isolated 24v current sourcing 250 mA outputs
