Connecting to the iSTAR Web Page Diagnostic Utility
5–36 iSTAR eX Installation and Configuration Guide
3. If you configured a Controller password in the C•CURE 800/8000, as
shown in Figure 5.14, the Enter Network Password dialog box opens, as
shown in Figure 5.15. (Controller Password is entered in System Variables
in both C•CURE 800/8000 and C•CURE 9000.)
Figure 5.14: Configure Controller Network Password
4. If a Controller password exists, as shown in Figure 5.14, enter the
password in both the User Name and Password fields of the Enter
Network Password Dialog box.
NOTE
If there is no Controller password, configure one on the System Variables
Controller Tab, by entering up to 16 characters.
