Chapter 3: System Installation 00.053.204, Revision A SonixTouch Q+ Service Manual
3-10
17. Unlock all casters (1: total lock, 2: completely unlocked).
18. Depending on whether the system is being unloaded from the front or back of the packing crate, use the rear
handles to push or pull the system down the ramps and off the palette.
Caution: Because the wheels sit in depressions, the system will have to be semi-lifted out of these in order to
roll it down the ramp.
