Unify OpenStage 15

administration.fm
A31003-S2030-M100-11-76A9, 01/2015
OpenStage SIP V3R3 for OpenScape Voice, Administration Manual
167
Administration
Free Programmable Keys
• LED controller URI: Indicates the state of the call number specified.
• Push support : Enables or disables LED control by push requests from the server.
• Symbolic name : Assigns a push request to the appropriate free programmable key resp.
fixed function key.
Administration via WBM
System > Features > Program keys > Send URL
Protocol
Web server address
Send URL
SIP response handling
Authenticate phone
Message details
HTTPS
GET
Web server user ID
Web server password
LED controller URI
Method
(key1=value1&key2=value2)
Port
Path
Parameters
Key label 2
Send URL
Symbolic name
Submit
Reset
Push support
Push support
