▪ Frequency
This selection assigns the Frequency algorithm to the selected analog channel.
▪ Harmonic
This selection assigns the Harmonic algorithm to the selected analog channel. The
specific harmonic to be calculated is entered in the Harmonic column.
▪ THD
This selection assigns the Total Harmonic Distortion (THD) algorithm to the
selected analog channel.
▪ Magnitude
This selection assigns the Magnitude algorithm to the selected analog channel.
This algorithm calculates the magnitude of the pure fundamental signal. This value
does not include any energy from harmonic distortion.
▪ Phasor
This selection assigns the Phasor algorithm to the selected analog channel.
▪ Delete
This selection completely removes the measurement.
Caution: Delete permanently removes all properties of the selected measurement.
o Group Type List:
These measurements are displayed when a Line Group is selected. The list below displays
all group measurement types. The specific group selected may have a reduced list of
choices based on the available channels and channel types within the group.
▪ Positive Sequence (Voltage)
This selection assigns the Positive Sequence algorithm to the three-phase voltage
channels in the selected group.
▪ Negative Sequence (Voltage)
This selection assigns the Negative Sequence algorithm to the three-phase
voltage channels in the selected group.
▪ Zero Sequence (Voltage)
This selection assigns the Zero Sequence algorithm to the three-phase voltage
channels in the selected group.
▪ Positive Sequence (Current)
This selection assigns the Positive Sequence algorithm to the three-phase current
channels in the selected group.
