usi M9000 - Figure 2-19 Start;End Date;Time Entries; Figure 2-20 Calendar Window

55
Figure 2-19 Start/End Date/Time Entries
o Enter Start Date/Time, End Date/Time:
These fields are used to select the begin and end dates and times to be displayed
on the DDR Analog table.
▪ Calendar button
This button displays the calendar window. This window is used to select
dates for the Start Date and End Date fields.
Figure 2-20 Calendar Window
▪ Up/Down buttons
These buttons are used to select times for the Start Time and End Time
fields (HH=Hours, MM=Minutes, SS=Seconds).
▪ This button is used to search the DDR Analog data for
records within the time period selected in the Date–Time Filter.
▪ This button is used to zero the entries in the Date-Time Filter.
• DDR Analog Data Table
This table displays the following DDR Analog record information.
