• Date-Time Filter
This panel is used to select a time-slice of continuous data to be displayed. To display this
panel, select a row in the Continuous Analog Data table.
Figure 2-28 Start/End Date/Time Entries
o Enter Start Date/Time, End Date/Time:
These fields are used to select the begin and end dates and times of the data
time-slice to be displayed.
Caution: Selecting more than one minute of continuous analog waveform data can result in
memory overflow requiring a browser restart.
▪ Calendar button
This button displays the calendar window. This window is used to select
dates for the Start Date and End Date fields.
Figure 2-29 Calendar Window
▪ Up/Down buttons
These buttons are used to select times for the Start Time and End Time
fields (HH=Hours, MM=Minutes, SS=Seconds).
▪ This button is used to display the continuous data within
the time period selected in the Date–Time Filter (see Section 4).
▪ This button is used to zero the entries in the Date-Time Filter.
