58
Figure 2-24 Calendar Window
▪ Up/Down buttons
These buttons are used to select times for the Start Time and End Time
fields (HH=Hours, MM=Minutes, SS=Seconds).
▪ This button is used to search the DDR RMS data for records
within the time period selected in the Date–Time Filter.
▪ This button is used to zero the entries in the Date-Time Filter.
• DDR RMS Data Table
This table displays the following DDR RMS record information.
Figure 2-25 DDR RMS Data Table
o Fault:
This column displays the identification number associated with the records.
