▪ Button

This button returns the display to the New Configuration Preview page.

▪ Button

This button saves the chassis portion of the DME configuration and displays the

Analog Channels Configuration page (see Section 3.1.2).

▪ Button

This button is used to finish the configuration wizard session. It saves the

configuration to a file and returns the display to the Home screen (Figure 2-2).

3.1.2 Analog Channels Configuration

This page is used to assign the parameters for each analog input channel. For reference, the channels are

automatically grouped and labeled by chassis (e.g. DFR1, DFR2, etc.).
