o ●Green:
This indicates a normal condition; the disk free space is normal.
o ●Red:
This indicates an alarm condition. The disk free space is less than 20%.
• TEMPERATURE
This LED indicates the temperature status of the M9000 module
o ●Green:
This indicates a normal condition, the DFR temperature is normal.
o ●Red:
This indicates an alarm condition, the DFR temperature is either over or under the limit
settings.
o ●Yellow:
This indicates an alarm condition, the DFR temperature is OK but is within 10°C of the
high limit.
• (UNUSED)
This LED is reserved for future use.
