HP10E / HP12E / HP15E / HP20E - Dairy design7. Cleaning
7-6 © VEMAG 2013
• Remove the sealing ring (1) from the hopper ange (2). Use the ap-
propriate tool at the cleaning plug (3) to do this.
1 Sealing ring
2 Hopper ange
3 Cleaning plug
Fig. 7-8
Feed unit seal
1
2
3
• Remove the sealing ring (1) from the hopper insert (2). Use the ap-
propriate tool at the cleaning plug (3) to do this.
1 Sealing ring
2 Hopper insert
3 Cleaning plug
Fig. 7-9
Feed unit seal
1
2
3
• Thoroughly clean the sealing rings, being sure to remove all product.
• The groove should be thoroughly cleaned, wiped out and inspected.
