HP10E / HP12E / HP15E / HP20E - Dairy design 8. Maintenance
8-11© VEMAG 2013
8.6 Weekly maintenance
8.6.1 Feed unit drive (lubrication)
The feed unit drive and the bearing must be lubricated twice a week with
the feed unit running slowly until grease escapes at the relief bore at the
outlet side of the machine. Use only high-performance grease which is
safe for food use and which is resistant to cleaning agents and disinfec-
tants.
• To do so, connect the grease gun supplied to the left-hand lubricating
nipple (1) at the outlet side of the machine and pump several full stro-
kes with the feed unit running until clean grease escapes from relief
bore (2).
• Then remove the grease which has escaped.
1 Lubricating nipple
2 Relief bore
Fig. 8-11
Lubricating the feed unit
drive
2
1
• If no grease at all escapes at the relief bore, inform VEMAG Customer
Service and have the drive/bearing checked.
