VEMAG HP12E - Fitting the Filling Horn Holder

HP10E / HP12E / HP15E / HP20E - Dairy design4. Setting up
4-4 © VEMAG 2013
4.4 Fitting the lling horn holder
• Inspect the locking ring and the threads for residual product prior to
assembly.
• Adjust locking nut (1) so that the handle is between the 10 and 11
o’clock position and insert lling horn holder (2).
• Turn locknut (1) clockwise to lock the lling horn holder. The handle
should now be approximately vertical.
1 Locking nut
2 Filling horn holder
Fig. 4-5
Locking the lling horn
holder
1
2
• Further attachments (optional) can be connected to the lling horn
holder.
Optional attachments are described separately
Operating instructions attachment (optional)
