VEMAG HP12E - Portion Delay

HP10E / HP12E / HP15E / HP20E - Dairy design 6. Graphical control
6-53© VEMAG 2013
6.6.4.54 Type of special control
Display: Special control
Selection Off / Fill / Separate / Start instruction / Ready
Application: Special controls using remote-P contact
• Select special control.
• Press Enter.
„Off“ = Special control switched off
„Fill“ = The signal becomes active at the beginning of
the rst portion and inactive at the end of pro-
duction (e.g. conveyor belt, watering system).
„Separate“ = The remote-P contact changes status with each
clipping pulse (e.g. wire cutter) or the ller stops
when the remote-D contact becomes active for
Knee II (e.g. stopping the lling process if the
subsequent machine is not ready).
„Start instruction“ = The signal becomes active when starting using
the knee-lever or remote-C, also when the main
drive must continue to wait (e.g. starting the
subsequent machine, although the main drive
for the ller is not yet ready).
„Ready“ = All conditions for start of production are fullled
(e.g. ready signal for subsequent machine).
6.6.4.55 Portion delay
Display: Portion delay
Selection: Off / Time / Signal A-C / Signal S-M / Coex
Unit: Milliseconds [ms]
Resolution: 1 ms
Setting range: 10 – 999 ms
Application: Cutter, coextrusion, diaphragm
• Enter portion delay (e.g. position of inner lling on Coex).
• Press Enter.
You can enter a delay time (positive values) or an advance time (negative
values) for the B machine in the portioning computer of the A machine.
If you select “Signal A-C” or “Signal S-M”, the lling machine starts on a
release signal.
