6.2 Screen
The screen is divided into ve different areas:
• Header
• Program and mode (mode group, mode, view, start/stop method)
• Parameters on the left-hand side of the screen
• Parameters on the right-hand side of the screen
• Footer
6.2.1 Header
The following information is displayed in the header:
• Depending on selection; pieces, portions per minute,
quantity in kg or speed (only in straight lling mode)
• Time
• Parameter number if there are more than six
(e.g. 1/11 = parameter no. 1 of 11)
• Arrows for direction of travel of the lifting and tipping device (optional)
6.2.2 Program and mode
Program number and product name (if entered) are displayed on the left-
hand side of the screen.
Section 6.5.1
The mode group (top), mode (centre), view (bottom) and start/stop
method are displayed on the right-hand side of the screen.
Section 6.5.2
A function key is assigned to these elds.
6.2.3 Basic parameters
The six basic parameters for the lling program in question are displayed
on the left-hand side of the screen. It is not possible to change the view
of these parameters. A function key is assigned to each of the six elds.
6.2.4 Supplementary parameters
Up to six supplementary parameters for the selected parameter
set are displayed on the right-hand side of the screen. The view
of these parameters can be changed using the Screen up/down keys.
You can modify and save the view of these parameters by modifying
the parameter set. A function key is assigned to each of the six elds.
6.2.5 Footer
The footer displays status and error messages.
Section 6.4
