VEMAG HP12E - Select Pumping System; Stop Counter; Soft Start-Up

HP10E / HP12E / HP15E / HP20E - Dairy design 6. Graphical control
6-33© VEMAG 2013
6.6.4.6 Select pumping system
Display: Pumping system
Selection: Rotary vane pump type (e.g. 10-rotor)
Application:
Fillers with rotary vane pump
• Enter rotary vane pump type.
• Press Enter.
6.6.4.7 Stop counter
Display: Stop counter
Unit: Number
Resolution: 1
Setting range: 1 – 9,999
Application: Stopping the machine automatically after a set number
of portions
• Enter the number of portions after which the machine is to stop.
• Press Enter.
The stop counter is active if a value greater than zero is entered.
The stop counter has two functions.
1. Stopping and resetting the counter as soon as the selected number
of pieces is reached (default).
2. Stopping and resetting the counter if more than 4 seconds have
passed since the machine was stopped using the knee lever. To execute
this function, use the Enter key to put a tick in the "Auto reset" eld.
6.6.4.8 Soft start-up
Display: Soft start-up
Selection: Off / On / All portions / First portion / LPG / Ramp adjust-
ment
Unit: Milliseconds [ms]
Resolution: 1 ms
Setting range: Machine-dependent - 9,999 ms
Application: Starting up the lling process gently
• Enter delay for a softer start-up to the lling process.
• Press Enter.
