HP10E / HP12E / HP15E / HP20E - Dairy design 6. Graphical control
6-39© VEMAG 2013
6.6.4.21 Conveyor belt calibre/discharge conveyor calibre
Display: Conveyor belt calibre/discharge conveyor calibre
Unit: Millimeter [mm]
Resolution: 1 mm
Setting range: dependent on calibre
Application: FSL 210 / FSL 211 (conveyor belt calibre only)
• Enter the conveyor belt calibre/discharge conveyor calibre.
• Press Enter.
The distance between the conveyor and discharge conveyor belts can be
adjusted. When adjusting the distance, the calibre limits specied in the
calibre parameter cannot be exceeded.
Example FSL 210:
Calibre = 22
Correction value bottom limit = -8, as 22 - 8 = 14
Correction value top limit = 18, as 22 + 18 = 40
6.6.4.22 Cut quantity
Display: Cut quantity
Unit: Number
Resolution: 1
Setting range: Off / 1 – 10
Application: FSL 210
• Enter the number of sausages between the cuts (e.g. „3“ if sections
with three sausages are to be cut).
• Press Enter.
• If the rst portion of one section of casing must always be cut off, tick
the „First portion“ eld by pressing Enter.
If you want to return to the rst portion of a section of casing as the
number of remaining portions on the current section of casing is smaller
than the specied value, tick the „Auto reset“ eld by pressing Enter.
Example:
Cut quantity = 5
Remaining portions = 3
The count begins with the new section of casing.
6.6.4.23 Link point stretch/cut distance
Display: Link point stretch/cut distance
Unit: Per cent [%] / Millimetre [mm]
Resolution: 1 % / 1 mm
Setting range: -50 – +50 % / -200 – +200 mm
Application: FSL 210
• Enter the link point stretch/cut distance.
• Press Enter.
