9-6 Videojet DataFlex 6530 Illustrated Parts Breakdown - Rev AA
Illustrated Parts List
Figure 9-5: Printer
Item Part Number Descriptions Quantity Sub-assembly
B 407974 Spare Videojet DataFlex
6530 Printer - RH (only)
1
407975 Spare Videojet DataFlex
6530 Printer - LH (only)
1
B1 Printer Assembly Refer to Table 9-7
B2 Printhead Assembly Refer to Table 9-8
B3 Cassette Assembly Refer to Table 9-9
Table 9-6: Printer_Parts List
B
B1
B3
B2
