C-2 Videojet DataFlex 6530 Service Manual - Rev AA
Note: TP4, TP8, TP46, TP58, TP83, TP85 DGND test points can be used as DGND reference.
TP16 +24V (top left segment of PCB) 23.5 - 24.5 V
TP42 +1V5 (mid segment of PCB) 1.45 - 1.55 V
TP88 +1V2 (bottom right segment of PCB) 1.15 - 1.25 V
TP45 +2V5 (mid right segment of PCB) 2.45 - 2.55 V
TP47 +1V1 (mid right segment of PCB) 1.00 - 1.15 V
TP86 +0V75 (bottom right segment of PCB) 0.735 - 0.765 V
TP17 19.5V PHDVS (top right segment of PCB) 19.0 - 20.0 V
Test Point Voltage/PCB Label and location Acceptable Voltage Range
Table C-1: Main Board Test Points (Continued)
