Videojet DataFlex 6530 Service Manual - Rev AA 4-21
Installation
Printer Is Busy The printhead is out in its printing position
Printer Is Not Busy The printhead is retracted from its printing position
Printer Is Offline The Stop button has been pressed and the printer is not
ready to run
Printer Is Online The Start button has been pressed and the printer is
ready to run
Printer Leaves Fault The fault condition has been cleared
Printer Leaves Warning The warning condition has been cleared
Printer Starts Printing The printer has started to physically print onto the
product
Radial Traverse Direction Is Active
Radial Traverse Direction Is Not
Active
Radial Traverse Step Is Active
Radial Traverse Step Is Not Active
Reject Is Active The printer has rejected a print/product
Reject Is Not Active The 'reject' output has been cleared
Options Description
Table 4-3: External Output Options (Continued)
