WinGD RT-flex50DF - Page 86

Maintenance0803−1/A2
Winterthur Gas & Diesel Ltd.
2/ 2
Longitudinal Section
WCH03431
2303−1
1132−2
2722−1
4325−1
2124−1 to
2124−3
4103−3
2751−1 to
2751−4
3403−1 to
3403−4
2708−1 to
2708−3
3140−1
3303−1 to
3303−5
3130−1
3425−1
1903−1
1224−1
1132−1
2138−1
1203−1
Fig. 2: Longitudinal Section
Engine Cross Section and Longitudinal Section (TC at Exhaust Side)
2016
