wsm B2420 - Servicing Specifications

CLUTCH
B2420, WSM
2-S2
2. SERVICING SPECIFICATIONS
9Y1210436CLS0002US0
Item Factory Specification Allowable Limit
Clutch Pedal Free travel on
Clutch Pedal
Distance "A"
20 to 30 mm
0.8 to 1.2 in.
5.5 to 6.0 mm
0.22 to 0.24 in.
–
–
Clutch Disc Boss to Gear Shaft Backlash
(Displacement
Around Disc Edge)
– 2.0 mm
0.079 in.
Clutch Disc Disc Surface to
Rivet Top (Depth)
–0.30 mm
0.012 in.
Pressure Plate Flatness – 0.2 mm
0.008 in.
KiSC issued 06, 2012 A
