FRONT AXLE
B2420, WSM
6-S3
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: See page G-10.)
9Y1210436FAS0003US0
Item N·m kgf·m lbf·ft
Front wheel mounting nut 80.0 to 110 8.20 to 11.2 59.0 to 81.1
Drag link slotted nut 18 to 35 1.9 to 3.5 14 to 25
Front axle bracket mounting screw 124 to 147 12.6 to 15.0 91 to 108
Tie-rod slotted nut 18 to 35 1.9 to 3.5 14 to 25
Bevel gear case mounting screw 78 to 90 7.9 to 9.2 58 to 66
Knuckle arm mounting screw (M10) 48 to 55 4.9 to 5.7 36 to 41
Knuckle arm mounting screw (M12) 103 to 117 10.5 to 12.0 76.0 to 86.7
Axle flange mounting screw 48 to 55 4.9 to 5.7 36 to 41
