BRAKES
B2420, WSM
5-S2
2. SERVICING SPECIFICATIONS
9Y1210436BRS0003US0
Item Factory Specification Allowable Limit
Brake Pedal Free Travel 30 to 40 mm
1.2 to 1.5 in.
–
Pedal Shaft to Center Frame
• Pedal Shaft
•Bush
Clearance
O.D.
I.D.
0 to 0.165 mm
0 to 0.00649 in.
24.916 to 25.030 mm
0.98095 to 0.98543 in.
25.030 to 25.081 mm
0.98544 to 0.98744 in.
1.0 mm
0.039 in.
–
–
Cam Plate and Bearing Holder Flatness – 0.30 mm
0.012 in.
Cam Plate and Ball Height 22.89 to 22.99 mm
0.9012 to 0.9051 in.
22.40 mm
0.8819 in.
Brake Disc Thickness 3.30 to 3.50 mm
0.130 to 0.137 in.
3.0 mm
0.12 in.
Friction Plate Thickness 1.92 to 2.08 mm
0.0756 to 0.0818 in.
1.52 mm
0.0598 in.
