wsm B2420 - Brake Lamp

ELECTRICAL SYSTEM
B2420, WSM
9-M20
[3] BRAKE LAMP
The brake switch is turned on when stepping on the brake pedal, and the brake lamp is lighted up.
9Y1210436ELM0014US0
Brake Lamp Switch
Brake lamp switch is turned on by pushing a brake
pedal and turned off by releasing it.
9Y1210436ELM0015US0
(1) Brake Lamp Switch A: OFF Position
B: ON Position
KiSC issued 06, 2012 A
