STEERING
B2420, WSM
7-S2
2. SERVICING SPECIFICATIONS
HYDRAULIC PUMP FOR POWER STEERING
Item Factory Specification Allowable Limit
Pump Delivery at no pressure Above
9.8 L/min.
2.6 U.S.gals/min.
2.2 lmp.gals/min.
–
Gear to Casing Clearance – 0.15 mm
0.0059 in.
Gear Shaft to Bushing
•Gear Shaft
• Bushing
Clearance
O.D.
I.D.
0.020 to 0.091 mm
0.00079 to 0.0035 in.
14.970 to 14.980 mm
0.58937 to 0.58976 in.
15.000 to 15.061 mm
0.59056 to 0.59295 in.
0.12 mm
0.0047 in.
–
–
Side Plate Thickness 2.48 to 2.50 mm
0.0977 to 0.0984 in.
2.40 mm
0.0945 in.
