wsm B2420 - Servicing Specifications

FRONT AXLE
B2420, WSM
6-S2
2. SERVICING SPECIFICATIONS
9Y1210436FAS0002US0
Item Factory Specification Allowable Limit
Front Wheel Alignment Toe-in 0 to 20 mm
0 to 0.78 in.
–
Front Axle Rocking Force 50.0 to 100 N
5.10 to 10.1 kgf
11.3 to 22.4 lbf
–
Differential Case to Deferential Pinion
• Differential Case
• Differential Case
Clearance
I.D.
O.D.
0.032 to 0.068 mm
0.0013 to 0.0026 in.
15.000 to 15.018 mm
0.59056 to 0.59125 in.
14.950 to 14.968 mm
0.58859 to 0.58929 in.
0.2 mm
0.008 in.
–
–
Spiral Bevel Pinion Shaft Turning Torque 0.80 to 1.0 N·m
0.082 to 0.10 kgf·m
0.59 to 0.73 lbf·ft
–
Spiral Bevel Pinion Shaft to Spiral Bevel
Gear
Backlash 0.1 to 0.3 mm
0.004 to 0.01 in.
–
10T Bevel Gear to 16T Bevel Gear Backlash 0.1 to 0.3 mm
0.004 to 0.01 in.
–
Front Axle Case Boss to Bracket Bushing
(Front)
• Front Axle Case Boss
• Bracket Bushing
Clearance
O.D.
I.D.
0.125 to 0.280 mm
0.00493 to 0.0110 in.
49.950 to 49.975 mm
1.9666 to 1.9675 in.
50.10 to 50.23 mm
1.973 to 1.977 in.
0.45 mm
0.018 in.
–
–
Front Axle Case Boss to Bracket Bushing
(Rear)
• Front Axle Case Boss
• Bracket Bushing
Clearance
O.D.
I.D.
0.0900 to 0.250 mm
0.00355 to 0.00984 in.
64.940 to 64.970 mm
2.5567 to 2.5578 in.
65.06 to 65.19 mm
2.562 to 2.566 in.
0.45 mm
0.018 in.
–
–
KiSC issued 06, 2012 A
