ENGINE
B2420, WSM
1-S9
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: See page G-10.)
[TRACTOR BODY]
[ENGINE]
• In removing and applying the bolts and nuts marked with "*", a pneumatic wrench or similar pneumatic
tool, if employed, must be used with enough care not to get them seized.
• For "*" marked screws, bolt and nuts on the table, apply engine oil to their threads and seats before
tightening.
• The letter "M" in Size x Pitch means that the screw, bolt or nut dimension stands for metric. The size is
the nominal outside diameter in mm of the threads. The pitch is the nominal distance in mm between two
threads.
9Y1210436ENS0003US0
Item N·m kgf·m lbf·ft
Steering wheel mounting nut 30 to 49 3.0 to 5.0 22 to 36
Drag link slotted nut 18 to 35 1.9 to 3.5 14 to 25
Power Steering delivery pipe nut 65 to 75 6.7 to 7.6 48 to 55
Front axle frame mounting screw 78 to 90 7.9 to 9.2 58 to 66
Clutch housing and engine mounting screw (M8) 18 to 21 1.8 to 2.1 13 to15
Clutch housing and engine mounting nut (M10) 48 to 55 4.9 to 5.7 36 to 41
Clutch cover mounting screw 24 to 27 2.4 to 2.8 18 to 20
Front lower frame mounting bolt (M12, 7T) [If equipped] 77.5 to 90.1 7.9 to 9.2 58.0 to 66.0
Front frame mounting bolt (M14, 9T) [If equipped] 167 to 196 17.0 to 20.0 123 to 145
Upper frame mounting bolt (M16, 7T) [If equipped] 196 to 225 20.0 to 23.0 145 to 166
Item Size × Pitch N·m kgf·m lbf·ft
Cylinder head cover cap nut M7 × 1.0 7 to 8 0.7 to 0.9 5 to 6
Injection pipe retaining nut M12 × 1.5 25 to 34 2.5 to 3.5 18 to 25
Nozzle holder assembly M20 × 1.5 49 to 68 5.0 to 7.0 37 to 50
Nozzle holder – 35 to 39 3.5 to 4.0 26 to 28
Overflow pipe assembly retaining nut M12 × 1.5 20 to 24 2.0 to 2.5 15 to 18
Glow plug M8 × 1.0 7.9 to 14 0.8 to 1.5 5.8 to 10
*Rocker arm bracket nut M7 × 1.0 22 to 26 2.2 to 2.7 16 to 19
*Cylinder head screw M10 × 1.25 64 to 68 6.5 to 7.0 47 to 50
Fan drive pulley retaining screw M14 × 1.5 236 to 245 24.0 to 25.0 174 to 180
*Connecting rod screw M8 × 1.0 42 to 46 4.2 to 4.7 31 to 33
*Flywheel screw M12 × 1.25 54 to 58 5.5 to 6.0 40 to 43
*Main bearing case screw 1 M8 × 1.25 30 to 34 3.0 to 3.5 22 to 25
*Main bearing case screw 2 M9 × 1.25 49 to 53 5.0 to 5.5 37 to 39
Bearing case cover mounting screw M6 × 1.0 9.81 to 11.2 1.00 to 1.15 7.24 to 8.31
