wsm B2420 - Troubleshooting

BRAKES
B2420, WSM
5-S1
1. TROUBLESHOOTING
9Y1210436BRS0002US0
Symptom Probable Cause Solution
Reference
Page
Uneven Braking
Force
Brake pedal free travel unevenly adjusted Adjust 5-S4
Brake disc worn Replace 5-S8
Cam plate warped Replace 5-S9
Brake Drags Brake pedal free travel too small Adjust 5-S4
Ball holes of cam plate for uneven wear Replace 5-S9
Brake pedal return spring weaken or broken Replace –
Brake cam rusted Repair 5-S9
Poor Braking Force Brake pedal free travel excessive Adjust 5-S4
Brake disc worn Replace 5-S8
Cam plate warped Replace 5-S9
Brake cam or lever damaged Replace 5-S9
Transmission fluid improper Change G-8
