REAR AXLE
B2420, WSM
4-S2
2. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: See page G-10.)
9Y1210436RAS0002US0
Item N·m kgf·m lbf·ft
Rear wheel mounting nut 123 to 147 12.5 to 15.0 90.8 to 108.0
Rear axle case mounting screw 40 to 44 4.0 to 4.5 29 to 32
KiSC issued 06, 2012 A
