GENERAL
B2420, WSM
G-51
10. IMPLEMENT LIMITATIONS
The KUBOTA Tractor has been thoroughly tested for proper performance with implements sold or approved by
KUBOTA. Use with implements which are not sold or approved by KUBOTA and which exceed the maximum
specifications listed below, or which are otherwise unfit for use with the KUBOTA Tractor may result in malfunctions
or failures of the tractor, damage to other property and injury to the operator or others. [Any malfunctions or failures
of the tractor resulting from use with improper implements are not covered by the warranty.]
WSM000001GEG0083US0
• Implement size may vary depending on soil operating conditions.
9Y1210436GEG0066US0
Tread (max. width) with farm tires
Lower link end max. loading
weight W0
Front Rear
B2420 200 kg (440 lbs) 920 kg (2028 lbs) 300 kg (661 lbs)
Actual figures
Implement Weight W1 and / or
size
Max. Drawbar Load W
2
Trailer loading weight W3
Max. capacity
B2420
As in the following list
(shown on the next page)
300 kg (661 lbs) 1000 kg (2205 lbs)
Lower link end max. hydraulic lifting capacity W0: The max. allowable load which can be put on the lower link end
Implement weight W1: The implement's weight which can be put on the lower link
Max. drawbar load W2
Trailer loading weight W3: The max. loading weight for trailer (without trailer's weight)
To Next Page
