GENERAL
B2420, WSM
G-28
[11] CHECK POINTS OF EVERY 2 YEARS
Replacing Fuel Hoses
• See page G-24.
9Y1210436GEG0049US0
Replacing Intake Air Hoses
• See page G-24.
9Y1210436GEG0050US0
Replacing Radiator Hoses
• See page G-25.
9Y1210436GEG0051US0
Flushing Cooling System and Changing Coolant
To avoid personal injury:
• Do not remove the radiator cap (1) while coolant is hot.
When cool, slowly rotate cap to the first stop and allow
sufficient time for excess pressure to escape before
removing the cap completely.
1. Stop the engine, remove the key and let it cool down.
2. To drain the coolant, open the radiator drain cock (2) and
remove the radiator cap (1). The radiator cap (1) must be
removed to completely drain the coolant.
3. After all coolant is drained, close the drain cock (2).
4. Fill with clean water and cooling system cleaner.
5. Follow directions of the cleaner instruction.
6. After flushing, fill with clean water and anti-freeze until the
coolant level is just below the radiator cap (1). Install the radiator
cap (1) securely.
7. Fill with coolant up to the "FULL" mark on the recovery tank (3).
8. Start and operate the engine for few minutes.
9. Stop the engine, remove the key and let cool.
10. Check coolant level of recovery tank (3) and add coolant if
necessary.
11. Properly dispose of used coolant.
• Do not start engine without coolant.
• Use clean, fresh water and anti-freeze to fill the radiator and
recovery tank.
• When the anti-freeze is mixed with water, the anti-freeze
mixing ratio must be less than 50 %.
• Securely tighten radiator cap. If the cap is loose or
improperly fitted, water may leak out and the engine could
overheat.
(To be continued)
Coolant
(with recover tank)
Capacity
3.9 L
4.1 U.S.qts
3.4 Imp.qts
(1) Radiator Cap
(2) Drain Cock
(3) Recovery Tank
(A) FULL
(B) LOW
To Next Page
