wsm B2420 - Engine Starting Conditions and Automatic Engine Stop

ELECTRICAL SYSTEM
B2420, WSM
9-M7
(1) Engine Starting Conditions and Automatic Engine Stop
When the following conditions become complete, electric current (12 V) reaches starter S terminal through
operator presence controller main switch and the engine can be started.
Engine Starting Conditions and Engine Auto-stop Conditions
* Engine Starting Condition: PTO neutral and main gear shift neutral
9Y1210436ELM0033US0
Rear PTO Switch
Main Gear Shift
Lever Switch
Parking Brake
Switch
Seat Switch Engine Start Key Stop Output
Neutral:
(Switch ON)
Engaged:
(Switch OFF)
Neutral:
(Switch ON)
Engaged:
(Switch OFF)
Lock:
(Switch ON)
Unlock:
(Switch OFF)
Sit: (Switch ON)
Stand:
(Switch OFF)
ON: Engine Start
None: Engine
must not start
ON: Engine Stop
OFF: Engine Does
Not Stop
1* Neutral Neutral Lock Sit ON OFF
2* Neutral Neutral Lock Stand ON OFF
3* Neutral Neutral Unlock Sit ON OFF
4 Neutral Neutral Unlock Stand ON OFF
5 Neutral Engaged Lock Sit None OFF
6 Neutral Engaged Lock Stand None ON
7 Neutral Engaged Unlock Sit None OFF
8 Neutral Engaged Unlock Stand None ON
9 Engaged Neutral Lock Sit None OFF
10 Engaged Neutral Lock Stand None OFF
11 Engaged Neutral Unlock Sit None OFF
12 Engaged Neutral Unlock Stand None ON
13 Engaged Engaged Lock Sit None OFF
14 Engaged Engaged Lock Stand None ON
15 Engaged Engaged Unlock Sit None OFF
16 Engaged Engaged Unlock Stand None ON
KiSC issued 06, 2012 A
