GENERAL
B2420, WSM
G-47
[2] TREAD ADJUSTMENT
To avoid personal injury:
• When working on slopes or when working with trailer, set the wheel tread as wide as practical for
maximum stability.
• Support tractor securely on stands before removing a wheel.
• Do not work under any hydraulically supported devices. They can settle, suddenly leak down, or be
accidentally lowered. If necessary to work under tractor or any machine elements for servicing or
adjustment, securely support them with stands or suitable blocking beforehand.
• Never operate tractor with a loose rim, wheel or axle.
• Always attach tires as shown in the figure.
• If not attached as the figure, transmission parts may be damaged.
• Do not use tires larger than specified.
9Y1210436GEG0063US0
(1) Front Wheels
Front tread width can not be adjusted.
• Do not turn front discs to obtain wider tread.
9Y1210436GEG0064US0
6-12B, Farm 6-12, Farm 185-85D (7-12), Farm
Tread (a) 797 mm (31.4 in.) 796 mm (31.3 in.) 815 mm (32.1 in.)
(a) Tread
