wsm B2420 - 2. SERVICING SPECIFICATIONS

ELECTRICAL SYSTEM
B2420, WSM
9-S5
2. SERVICING SPECIFICATIONS
STARTER MOTOR
GLOW PLUG
9Y1210436ELS0023US0
Item Factory Specification Allowable Limit
Commutator O.D.
Difference of
O.D.'s
28.0 mm
1.10 in.
Less than
0.02 mm
0.0008 in.
27.0 mm
1.06 in.
0.05 mm
0.002 in.
Mica Undercut 0.60 mm
0.024 in.
0.20 mm
0.0079 in.
Brush Length 14.0 mm
0.551 in.
9.0 mm
0.35 in.
Item Factory Specification Allowable Limit
Glow Plug Resistance Approx. 0.9 Ω –
KiSC issued 06, 2012 A
