CLUTCH
B2420, WSM
2-S6
Draining Coolant
• Never open the radiator cap while operating or immediately
after stopping. Otherwise, hot water will spout out from the
radiator. Wait for more than ten minutes to cool the
radiator, before opening the cap.
1. Loosen the drain cock (3) from the radiator hose to drain
coolant.
2. Remove the radiator cap (1) to drain coolant completely.
9Y1210436ENS0021US0
Coolant
(with recovery tank)
Capacity
3.9 L
4.1 U.S.qts
3.4 lmp.qts
(1) Radiator Cap
(2) Recovery Tank
(3) Drain Cock
To Next Page
