STEERING
B2420, WSM
7-S4
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts: See page G-10.)
9Y1210436STS0003US0
Item N·m kgf·m lbf·ft
Drag link and slotted nut 18 to 35 1.9 to 3.5 14 to 25
Steering wheel mounting nut 30 to 49 3.0 to 5.0 22 to 36
Power steering delivery pipe nut 65 to 75 6.7 to 7.6 48 to 55
Return pipe nut 34 to 39 3.5 to 3.9 25 to 28
Power steering controller assembly mounting screw 78 to 90 7.9 to 9.2 58 to 66
Steering column mounting screw 28 2.9 21
Hydraulic pump cover mounting screw 35 to 39 3.5 to 4.0 26 to 29
Pitman arm mounting nut 140 to 150 14.3 to 15.3 103 to 111
Side cover mounting screw 20 to 29 2.0 to 3.0 15 to 21
Valve housing mounting hex. head screw 40 to 49 4.0 to 5.0 29 to 36
Plug 8.9 to 10 0.90 to 1.1 6.5 to7.9
Relief pressure adjusting screw lock nut 49 to 78 5.0 to 8.0 37 to 57
