GENERAL
B2420, WSM
G-26
Changing Transmission Fluid / Replacing Hydraulic Oil Filter
To avoid personal injury:
• Be sure to stop the engine before changing the oil filter
cartridge.
• Allow engine to cool down sufficiently, oil can be hot and
can burn.
1. To drain the used oil, remove the drain plugs (1) at the bottom
of the transmission case and drain the oil completely into the oil
pan.
2. After draining reinstall the drain plugs (1).
3. Remove the oil filter (2).
4. Put a film of clean transmission oil on rubber seal of new oil filter
(2).
5. Tighten the oil filter (2) quickly until it contacts the mounting
surface.
Tighten oil filter (2) by hand an additional 1/2 turn only.
6. Fill with new KUBOTA SUPER UDT fluid up to the upper notch
on the dipstick (3).
7. After running the engine for a few minutes, stop it and check the
oil level again; add oil to prescribed level.
8. After the new oil filter (2) has been replaced, the transmission
fluid level will decrease a little. Make sure that the transmission
fluid does not leak through the seal, and check the fluid level.
Top off if necessary.
9. Properly dispose of used oil.
• If the 3-point hitch can not be raised by setting the
hydraulic control lever to the UP position after long term
storage or when changing the transmission oil, turn
steering wheel to the right and left several times to bleed air
from the system.
• Use only multi-grade transmission oil. Use of other oils
may damage the transmission or hydraulic system. Refer
to "LUBRICANTS, AND FLUID" (See page G-8).
• Never work the tractor immediately after changing the
transmission oil. Keeping the engine at medium speed for
a few minutes to prevents damage to the transmission.
• Do not mix different brands oil together.
9Y1210436GEG0046US0
Transmission fluid Capacity
14 L
3.7 U.S.gals
3.1 lmp.gals
(1) Drain Plugs (Both sides)
(2) Oil Filter
(3) Filling Plug
(4) Dipstick
A: Oil level is acceptable within this
range.
