The tables below provide space requirements and machine dimensions.
Table 23: Space Requirements
84” (2135mm) clearance from floor to nearest overhead
obstruction within the floor space requirement
Height
140” (3550mm) recommended, 109” (2770mm) minimumWidth
132” (3347mm)Depth
Table 24: Machine Dimensions
55.1” (1400mm) - with UIHeight
61” (1550mm) - with UIWidth
33.3” (847mm) - with ControllerDepth
Table 25: Machine Weight
Ship WeightWeight
659 lb (299 kg)537 lb (244 kg)IOT
15 lb (6.8 kg)13.5 lb (6.1 kg)UI
24.4 lb (11 kg)19.2 lb (8.7 kg)Controller
698 lb (317 kg)570 lb (259 kg)IOT installed with UI and
Controller
135 lb (61 kg)80.5 lb (36.5 kg)2 Roll Option
