03/2003
7-73
8850/ 510DP
Plug/Jack List
Wiring Data
Plug/Jack List
The following list is provided as an aid in locating plugs and jacks and other components.
Refer to the referenced Block Schematic Diagram (BSD) for component location.
Table 1 Plug/Jack
Plug/Jack or Component Brief Description BSD Figure No.
A0B1P1/J1 Vacuum Transport Fan Motor Figure 8
A0L1P1/J1 Roll 1 Feed Clutch (L1) Figure 6
A0L2P1/J1 Roll 1 Rewind Clutch (L2) Figure 6
A0L3P1/J1 Roll 2 Feed Clutch (L3) Figure 6
A0L4P1/J1 Roll 2 Rewind Clutch (L4) Figure 6
A0L5P1/J1 Roll 3 Feed Clutch (L5) Figure 6
A0L6P1/J1 Roll 3 Rewind Clutch (L5) Figure 6
A0Q1P1J1 Roll 1 Paper Feed Sensor (Q1) Figure 5
A0Q2P1/J1 Roll 2 Paper Feed Sensor (Q2) Figure 5
A0Q3P1/J1 Roll 3 Paper Feed Sensor (Q3) Figure 5
A0Q4P1/J1 Roll 1 Motion Sensor (Q4) Figure 6
A0Q5P1/J1 Roll 2 Motion Sensor (Q5) Figure 6
A0Q6P1/J1 Roll 3 Motion Sensor (Q6) Figure 6
A1 AC Module BSD 1.1 Figure 1
A1FL1 Noise Filter BSD 1.1 Figure 2
A1GFP1 Ground Fault Protector BSD 1.1 Figure 2
A1J1 AC Power Module Figure 3
A1J2 AC Power Module Figure 3
A1P3/J3 AC Power Module BSD
10.1
Figure 1
A1P5/J5 Controller Power Cord BSD 1.1 Figure 1
A1P7/J7 AC Power Module Figure 1
A1P8/J8 AC Power Module Figure 1
A1P9/J9 AC Power Module Figure 1
A1P11/J11 AC Power Module Cooling Fan Figure 3
A1S1 Main Power Switch BSD 1.1 Figure 1,
Figure 2
A3P600/J600 Main PWB to Control Panel Figure 4
A3P601/J601 Main PWB BSD 2.1 Figure 4
A3P602/J602 Main PWB to Finishing Device Figure 4
A3P603/J603 Main PWB to NOHAD Fans, Devel-
oper Cover Interlock, and Media
Drawer Switches
BSD 9.7 Figure 4
A3P604/J604 Main PWB to Erase Bar Figure 4
A3P605/J605 Main PWB to High Voltage Power
Supply
BSD 4.1 Figure 4
A3P606/J606 Main PWB to Developer Module BSD
10.1
Figure 4
A3P607/J607 Main PWB to Media Registration
Sensor
BSD 6.1 Figure 4
A3P608/J308 Main PWB to LED Bar BSD 3.1 Figure 4
A3P609/J609 Main PWB to Roll Feed Sensors (Q1
- Q3) and Motion Sensors (Q4 - Q6)
Figure 4
A3P610/J610 Main PWB to P193 Interface Figure 4
A3P611/J611 Main PWB to RS 232 Interface Figure 4
A3P612/J612 Main PWB to Roll Feed (L1, L3, L5)
and Rewind (L2, L4, L6) Clutches
Figure 4
A3P612A/J612A Main PWB to Lower Transport and
Prefeed Sensor
Figure 4
A3P613/J613 Main PWB to Media Transport Drive
and Media Roll Feed Drive
BSD 3.1 Figure 4
A3P614/J614 Main PWB Figure 4
A3P615/J615 Main PWB to Paper Heater Figure 4
A3P616/J616 Main PWB to Cutter Assembly Figure 4
A3P617/J617 Main PWB from Low Voltage Power
Supply
Figure 4
A3P618/J618 Main PWB from Low Voltage Power
Supply
Figure 4
A3P619/J619 Main PWB to LED Bar Figure 4
A3P619A/J619A Main PWB to LED Bar Figure 5
A3P620/J620 Main PWB to Fuser and Developer
Drive Motors
Figure 4
A3P621/J621 Main PWB Drum Drive Motor, Front
Door Interlock Switch, and Vacuum
Transport Vacuum Fan
Figure 4
A3P622/J622 Main PWB to Print Count Meter Figure 4
A3J900 Main PWB to Ground Figure 4
A5P1/J1 LVPS BSD 1.2 Figure 5
A7P1/J1 Media Drive Motor PWB BSD 7.1 Figure 6
A7P2/J2 Media Drive Motor PWB BSD 7.1 Figure 6
A8M1P1/J1 Cutter Drive Motor BSD 7.5 Figure 7
A8Q1P1/J1 Cutter Home Sensor BSD 7.5 Figure 7
A9P1/J1 Lower Transport Drive Motor PWB Figure 6
A9P2/J2 Lower Transport Drive Motor PWB Figure 6
A20M1P1/J1 Fuser Roll Drive Motor BSD 4.1 Figure 8
A20M2P1/J1 Developer Drive Motor BSD 4.2 Figure 12
A20P2J2 Electronic Volt Meter (ESV) Figure 12
A21Q1P1/J1 Media Registration Sensor BSD 8.1 Figure 10
A22M1P1/J1 Toner Cartridge Drive Motor BSD 9.7 Figure 9
A22P1/J1 Developer Assembly BSD 9.7 Figure 8
A22Q1P1/J1
A22Q1P1A/J1A
Toner Sensor BSD 9.7 Figure 11,
Figure 12
Table 1 Plug/Jack
