Fax
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
6-2
• When a document containing pages of different sizes is placed in the machine, the machine uses
the largest document size to scan the document.
• The paper size for fax transmissions is different from the document sizes supporting automatic
detection. For more information, refer to Original Size on page 6-20.
Supported documents types (weights)
Documents with weights from 38 to 128 gsm (50 to 128 gsm for 2 Sided documents) can be placed in
the document feeder and scanned.
The document feeder accepts the following number of sheets.
Note To avoid paper jams, use the document glass for mixed size, folded, wrinkled, cut-and-pasted
documents, curled paper, or carbon-backed paper. If you can flatten the curled document, you can use
the document.
Follow the steps below to place document in the document feeder.
You can place a single or multiple pages of a document.
1. Remove any paper clips or staples from document before placing it in the document feeder.
2. Place the document in the center of the document feeder, with the side to be scanned (or the
front surface of a 2 Sided document) facing up.
3. Align the document guides to each side of document.
Document Type (gsm) Number of Sheets
Lightweight (38 to 49 gsm) 110 sheets
Plain (50 to 80 gsm) 110 sheets
Heavyweight (81 to 128 gsm) 75 sheets
To Next Page
