Xerox WorkCentre 5024

Scan
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
7-21
2. Select the desired file format, and then press the OK button.
Original Size
You can set the document size and orientation.
1. Select Original Size then press the OK button.
2. Select the document size, and then press the OK button.
Note Original Size is automatically set to Auto when document is placed in the document feeder.
PDF (default) Supports both Black & White and Color.
TIFF Selectable when Black & White is selected in Color Mode.
JPEG Selectable when Color is selected in Color Mode.
Auto The machine automatically detects the document size from the supported
standard sizes.
Fixed document size
(Preset)
Select the size of the placed document.
TIFF
File Format
JPEG
PDF
Original Size ... A4
Color Mode
... Color
File Format
... PDF
Scan to [01]
200
B4 (257x364mm)
B5 (182x257mm)
Original Size
A4 (210x297mm)
