Xerox WorkCentre 5024

Appendix
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
14-9
Duplex Output Unit (Optional)
One Tray Module (Optional)
Two Tray Module (Optional)
Paper Size Maximum: A3, 11 × 17"
Minimum: A5, B5
Paper Weight 60 - 90 gsm
Note: Use the bypass tray when using 91 - 110 gsm paper.
Paper Size Same as the Basic Functions/Copy Functions
Paper Weight 500 sheets x 1 tray
Note: When using 80 gsm paper.
Dimensions/
Weight
Width 540 × Depth 523 × Height 117 mm, 11 kg
Paper Size Same as the Basic Functions/Copy Functions
Paper Weight 500 sheets x 2 trays
Note: When using 80 gsm paper.
Dimensions/
Weight
Width 540 × Depth 523 × Height 290 mm, 31 kg
