Xerox WorkCentre 5024

Appendix
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
14-2
Basic Functions/Copy Functions
Type Desktop
Memory 256 MB
Scanning Resolution 600 × 600 dpi
Hard Disk -
Printing Resolution 600 × 600 dpi
Halftone 256 shades of gray scales
Warm-up Time 19 seconds or less
Note: At room temperature, 20°C
Original Paper Size The maximum size is 297 × 432 mm (A3, 11 × 17") for both sheets and books.
Image loss width: 5.5 mm max. at top, right, and left; 6.0 mm max. at bottom
Output Paper Size Maximum: A3, 11 × 17"
Minimum: Tray 1: A5
Tray 2 to 4: A5
Tray 5 (bypass): A5
Output Paper Weight Tray 1 (standard): 60 - 90 gsm
Tray 2 to 4 (optional): 60 - 216 gsm
Tray 5 (bypass): 60 - 216 gsm
Note: Use paper recommended by Xerox. Copying may not be performed
correctly depending on the conditions.
First Copy Output Time
Document glass: 7.2 sec. or less (A4 )
Document feeder: 11 sec. or less (A4 )
Reduction/Enlargement Size-for-Size 1:1 ± 0.8%
Preset % 1:0.500, 1:0.707, 1:0.816, 1:0.866, 1:1.154, 1:1.225, 1:1.414
1:2.000
Variable % 1:0.25 - 1:4.000% (1% increments)
