Xerox WorkCentre 5024

Fax
Xerox
®
WorkCentre
®
5022/5024 Multifunction Printer
User Guide
6-13
For example, to specify the fax recipient registered for Speed Dial 001, press the One Touch button 1.
Notes
• The One Touch buttons have sensors to detect which set of buttons (1 to 12, 13 to 24, or 25 to 36)
is activated. Turn over the One Touch panel completely before pressing the One Touch buttons.
• Take care not to place objects or spill liquids near the One Touch panel.
For information on how to register a Speed Dial entry, refer to Speed Dial on page 9-21.
1. Press the Fax button.
The Enter Recipient screen displays.
2. Press a One Touch button.
Example: Screen displayed when the One Touch button 1 is pressed to select 001 John Smith.
Note To specify a Speed Dial number higher than 013, turn over the panel.
3. Press the OK button.
Fax button
Resolution ... Standard
Enter Recipient
Recipient
...
Original Type ... Text
12
34
56
78
910
11 12
One Touch button
